Bearings, units and housings -- Super-precision bearings -- Angular contact ball bearings -- Angular contact ball bearings, super-precision -- SKF 71911 CE/P4A
71911 CE/P4A
Dimensions
| d | 55 | mm | |
| D | 80 | mm | |
| B | 13 | mm | |
| d1 | 62.75 | mm | |
| d2 | 60.7 | mm | |
| D1 | 72.3 | mm | |
| r1,2 | min. | 1 | mm |
| r3,4 | min. | 0.3 | mm |
| a | 16.2 | mm |
Abutment dimensions
| da | min. | 59.6 | mm |
| db | min. | 57 | mm |
| Da | max. | 75.4 | mm |
| Db | max. | 78 | mm |
| ra | max. | 1 | mm |
| rb | max. | 0.3 | mm |
| dn | 64.6 | mm |
Calculation data
| Basic dynamic load rating | C | 15.3 | kN | |
| Basic static load rating | C0 | 10.6 | kN | |
| Fatigue load limit | Pu | 0.455 | kN | |
| Attainable speed for grease lubrication | 24000 | r/min | ||
| Attainable speed for oil-air lubrication | 36000 | r/min | ||
| Ball diameter | Dw | 7.938 | mm | |
| Number of balls | z | 21 | ||
| Reference grease quantity | Gref | 2.3 | cm³ | |
| Preload and stiffness (back-to-back, face-to-face) | ||||
| Preload class A | GA | 83 | N | |
| Static axial stiffness, preload class A | 42 | N/µm | ||
| Preload class B | GB | 250 | N | |
| Static axial stiffness, preload class B | 67 | N/µm | ||
| Preload class C | GC | 500 | N | |
| Static axial stiffness, preload class C | 92 | N/µm | ||
| Calculation factors | ||||
| Calculation factor | f | 1.16 | ||
| Calculation factor | f1 | 1 | ||
| Calculation factor | f2A | 1 | ||
| Calculation factor | f2B | 1.04 | ||
| Calculation factor | f2C | 1.08 | ||
| Calculation factor | fHC | 1 | ||
| Calculation factor | f0 | 8.4 | ||
Mass
| Mass bearing | 0.17 | kg |
