Bearings, units and housings -- Ball bearings -- Angular contact ball bearings -- Single row angular contact ball bearings -- Angular contact ball bearings, single row SKF 71968 ACMB

71968 ACMB

Dimensions

d		340	mm
D		460	mm
B		56	mm
d₁	≈	380	mm
D₁	≈	422	mm
a		126	mm
r_1,2	min.	3	mm
r_3,4	min.	1.1	mm

Abutment dimensions

d_a	min.	353	mm
D_a	max.	447	mm
D_b	max.	453	mm
r_a	max.	2.5	mm
r_b	max.	1	mm

Calculation data

Basic dynamic load rating	C	338	kN
Basic static load rating	C₀	585	kN
Fatigue load limit	P_u	12.5	kN
Reference speed		1500	r/min
Limiting speed		1500	r/min
Calculation factor	k_r	0.083
Calculation factor	e	0.68
Single bearing or bearing pair arranged in tandem
Calculation factor	X	0.41
Calculation factor	Y₀	0.38
Calculation factor	Y₂	0.87

Mass

Mass bearing

Model Number: 71968 ACMB
Inner Diameter：340mm Outer Diameter：460mm Width：56mm
Reference speed:1500 r/min Limiting speed:1500 r/min
Type：Bearings, units and housings Ball bearings Angular contact ball bearings Single row angular contact ball bearings
Details： Single row angular contact ball bearings Angular contact ball bearings, single row
Update date：2026-06-24
Application:transportation equipment,vertical processing,Textile Accessories,Forklift industry,Machine tool accessories,special broaching machine,Spectrum Products,plant determination,position switch,ventilator anesthesia machine etc,coal mill
Similar models:71968 CDMA/HCP4A 71968 CDMA/P4A 71968 ACMB 71968 ACDMA/HCP4A 71968 ACDMA/P4A
BEARING POWER International Trading Co.,Ltd. specialize in 71968ACMB products，there is large inventory of SKF 71968 ACMB Single row angular contact ball bearings. We has been built up long-term cooperation with SKF company, could make a bulk order of the 71968 ACMB Which SKF 71968ACMB is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
