Bearings, units and housings -- Ball bearings -- Angular contact ball bearings -- Single row angular contact ball bearings -- Angular contact ball bearings, single row SKF 7200 BEP

7200 BEP

Dimensions

d		10	mm
D		30	mm
B		9	mm
d₁	≈	18.3	mm
d₂	≈	14.57	mm
D₁	≈	22.85	mm
a		13	mm
r_1,2	min.	0.6	mm
r_3,4	min.	0.3	mm

Abutment dimensions

d_a	min.	14.2	mm
D_a	max.	25.8	mm
D_b	max.	27.6	mm
r_a	max.	0.6	mm
r_b	max.	0.3	mm

Calculation data

Basic dynamic load rating	C	7.02	kN
Basic static load rating	C₀	3.35	kN
Fatigue load limit	P_u	0.14	kN
Reference speed		22000	r/min
Limiting speed		30000	r/min
Calculation factor	A	0.224
Calculation factor	k_r	0.095
Calculation factor	e	1.14
Single bearing or bearing pair arranged in tandem
Calculation factor	X	0.35
Calculation factor	Y₀	0.26
Calculation factor	Y₂	0.57
Bearing pair arranged back-to-back or face-to-face
Calculation factor	X	0.57
Calculation factor	Y₀	0.52
Calculation factor	Y₁	0.55
Calculation factor	Y₂	0.93

Mass

Mass bearing

0.03

Model Number: 7200 BEP
Inner Diameter：10mm Outer Diameter：30mm Width：9mm
Reference speed:30000 r/min Limiting speed:22000 r/min
Type：Bearings, units and housings Ball bearings Angular contact ball bearings Single row angular contact ball bearings
Details： Single row angular contact ball bearings Angular contact ball bearings, single row
Update date：2026-06-24
Application:security equipment,rubber products machinery and equipment,thread processing machine,joint protection,water,standing experimental equipment,preservation equipment,Machine tool accessories,steam Hydraulic control element,Broadcasting System,Gear grinding machine
Similar models:7200 CD/HCP4A 7200 BECBP 7200 CD/P4A S7200 CD/P4A S7200 ACD/HCP4A 7200 ACD/P4A 7200 BEP 7200 ACD/HCP4A S7200 CD/HCP4A S7200 ACD/P4A
BEARING POWER International Trading Co.,Ltd. specialize in 7200BEP products，there is large inventory of SKF 7200 BEP Single row angular contact ball bearings. We has been built up long-term cooperation with SKF company, could make a bulk order of the 7200 BEP Which SKF 7200BEP is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
