Bearings, units and housings -- Super-precision bearings -- Angular contact ball bearings -- Angular contact ball bearings, super-precision -- SKF 7201 CD/HCP4A
7201 CD/HCP4A
Dimensions
| d | 12 | mm | |
| D | 32 | mm | |
| B | 10 | mm | |
| d1 | 18.6 | mm | |
| d2 | 18.6 | mm | |
| D1 | 25.4 | mm | |
| r1,2 | min. | 0.6 | mm |
| r3,4 | min. | 0.3 | mm |
| a | 8 | mm |
Abutment dimensions
| da | min. | 16.2 | mm |
| db | min. | 16.2 | mm |
| Da | max. | 27.8 | mm |
| Db | max. | 29.6 | mm |
| ra | max. | 0.6 | mm |
| rb | max. | 0.3 | mm |
| dn | 20 | mm |
Calculation data
| Basic dynamic load rating | C | 5.85 | kN | |
| Basic static load rating | C0 | 2.55 | kN | |
| Fatigue load limit | Pu | 0.108 | kN | |
| Attainable speed for grease lubrication | 67000 | r/min | ||
| Attainable speed for oil-air lubrication | 95000 | r/min | ||
| Ball diameter | Dw | 5.556 | mm | |
| Number of balls | z | 10 | ||
| Reference grease quantity | Gref | 0.507 | cm³ | |
| Preload and stiffness (back-to-back, face-to-face) | ||||
| Preload class A | GA | 22 | N | |
| Static axial stiffness, preload class A | 18 | N/µm | ||
| Preload class B | GB | 44 | N | |
| Static axial stiffness, preload class B | 24 | N/µm | ||
| Preload class C | GC | 88 | N | |
| Static axial stiffness, preload class C | 33 | N/µm | ||
| Preload class D | GD | 176 | N | |
| Static axial stiffness, preload class D | 46 | N/µm | ||
| Calculation factors | ||||
| Calculation factor | f | 1.02 | ||
| Calculation factor | f1 | 1 | ||
| Calculation factor | f2A | 1 | ||
| Calculation factor | f2B | 1.01 | ||
| Calculation factor | f2C | 1.03 | ||
| Calculation factor | f2D | 1.06 | ||
| Calculation factor | fHC | 1.01 | ||
| Calculation factor | f0 | 8.5 | ||
Mass
| Mass bearing | 0.033 | kg |
