Bearings, units and housings -- Super-precision bearings -- Angular contact thrust ball bearings for screw drives -- Angular contact thrust ball bearings for screw drives, double direction, super-precision -- SKF BEAM 020068-2RZ/PE

BEAM 020068-2RZ/PE

Dimensions

d		20	mm
D		68	mm
H		28	mm
d₁		34.5	mm
D₁		44	mm
H₁		19	mm
r_1,2	min.	0.3	mm
r_3,4	min.	0.6	mm
a		74	mm
J		53	mm
N		6.8	mm

Abutment dimensions

d_a	min.	25	mm
D_a	max.	44	mm
r_a	max.	0.6	mm

Calculation data

Basic dynamic load rating	C	26	kN
Basic static load rating	C₀	46.5	kN
Fatigue load limit	P_u	1.73	kN
Attainable speed		6000	r/min
Preload		1650	N
Frictional moment		0.15	N·m
Static axial stiffnes		650	N/µm

Mass

Mass bearing

0.61

Mounting information

Required attachment bolt size	M6
Number of attachment bolts	7
Pitch	45	°

Model Number: BEAM 020068-2RZ/PE
Inner Diameter：20mm Outer Diameter：68mm Width：28mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Super-precision bearings Angular contact thrust ball bearings for screw drives Angular contact thrust ball bearings for screw drives, double direction, super-precision
Details： Angular contact thrust ball bearings for screw drives, double direction, super-precision
Update date：2026-05-14
Application:disposable,medical equipment,air shower etc,Automation,bathroom facilities,Traffic Fire Protection Equipment Security equipment,trolley,crimping tools,Medium and large motor,economic mold,paper processing machine
Similar models:BEAM 020068-2RZ BEAM 020068-2RZ/PE
BEARING POWER International Trading Co.,Ltd. specialize in BEAM020068-2RZ/PE products，there is large inventory of SKF BEAM 020068-2RZ/PE Angular contact thrust ball bearings for screw drives, double direction, super-precision. We has been built up long-term cooperation with SKF company, could make a bulk order of the BEAM 020068-2RZ/PE Which SKF BEAM020068-2RZ/PE is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
