Bearings, units and housings -- Super-precision bearings -- Angular contact thrust ball bearings for screw drives -- Angular contact thrust ball bearings for screw drives, double direction, super-precision -- SKF BEAM 060145-2RZ

BEAM 060145-2RZ

Dimensions

d		60	mm
D		145	mm
H		45	mm
d₁		85	mm
D₁		100	mm
H₁		35	mm
r_1,2	min.	0.6	mm
r_3,4	min.	0.6	mm
a		168	mm
J		120	mm
N		8.8	mm

Abutment dimensions

d_a	min.	82	mm
D_a	max.	100	mm
r_a	max.	0.6	mm

Calculation data

Basic dynamic load rating	C	85	kN
Basic static load rating	C₀	216	kN
Fatigue load limit	P_u	8	kN
Attainable speed		2600	r/min
Preload		4700	N
Frictional moment		1	N·m
Static axial stiffnes		1400	N/µm

Mass

Mass bearing

4.3

Mounting information

Required attachment bolt size	M8
Number of attachment bolts	8
Pitch	45	°

Model Number: BEAM 060145-2RZ
Inner Diameter：60mm Outer Diameter：145mm Width：45mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Super-precision bearings Angular contact thrust ball bearings for screw drives Angular contact thrust ball bearings for screw drives, double direction, super-precision
Details： Angular contact thrust ball bearings for screw drives, double direction, super-precision
Update date：2026-06-25
Application:motorcycle,education model Instruments,dynamic blood pressure,ECG,standing experimental equipment,altimeter etc,Energy saving energy saving energy saving energy saving energy saving energy saving energy saving energy saving energy saving energy saving energy saving,chuck industry,other rubber,decoration machinery,municipal machinery
Similar models:BEAM 060145-2RS BEAM 060145-2RZ
BEARING POWER International Trading Co.,Ltd. specialize in BEAM060145-2RZ products，there is large inventory of SKF BEAM 060145-2RZ Angular contact thrust ball bearings for screw drives, double direction, super-precision. We has been built up long-term cooperation with SKF company, could make a bulk order of the BEAM 060145-2RZ Which SKF BEAM060145-2RZ is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
