Bearings, units and housings -- Super-precision bearings -- Angular contact thrust ball bearings for screw drives -- Angular contact thrust ball bearings for screw drives, double direction, super-precision -- SKF BEAS 017047-2RZ

BEAS 017047-2RZ

Dimensions

d		17	mm
D		47	mm
H		25	mm
d₁		30	mm
D₁		38	mm
b		3.1	mm
K		2.5	mm
r_1,2	min.	0.3	mm
r_3,4	min.	0.6	mm
a		65	mm

Abutment dimensions

d_a	min.	23	mm
D_a	max.	40	mm
r_a	max.	0.3	mm
r_b	max.	0.6	mm

Calculation data

Basic dynamic load rating	C	19	kN
Basic static load rating	C₀	31	kN
Fatigue load limit	P_u	1.16	kN
Attainable speed		6300	r/min
Preload		720	N
Frictional moment		0.12	N·m
Static axial stiffnes		420	N/µm
Static moment stiffness		80	N·m/mrad

Mass

Mass bearing

0.22

Model Number: BEAS 017047-2RZ
Inner Diameter：17mm Outer Diameter：47mm Width：25mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Super-precision bearings Angular contact thrust ball bearings for screw drives Angular contact thrust ball bearings for screw drives, double direction, super-precision
Details： Angular contact thrust ball bearings for screw drives, double direction, super-precision
Update date：2026-06-19
Application:sample cup,car,bathroom facilities,Medical printer,van,tube,natural instruments,instrument,ventilation fans,supporting facilities,other accessories
Similar models:BEAS 017047-2RZ BEAS 017047-2RS
BEARING POWER International Trading Co.,Ltd. specialize in BEAS017047-2RZ products，there is large inventory of SKF BEAS 017047-2RZ Angular contact thrust ball bearings for screw drives, double direction, super-precision. We has been built up long-term cooperation with SKF company, could make a bulk order of the BEAS 017047-2RZ Which SKF BEAS017047-2RZ is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
