BMO-6204/048S2/UA108A

Dimensions
d 20mm
D 47mm
B1 20.2mm
B 14mm
d1≈28.8mm
d2 28.69mm
D1≈40.6mm
D2 46.56mm
D3 44.6mm
C 2.46mm
b 1.35mm
r0 0.4mm
r1,2min.1mm
L 558mm
 ±10mm
Abutment dimensions
damin.25mm
dbmin.25mm
dbmax.28.6mm
Damax.42mm
ramax.1mm
Sensor technology
Cable connector type  AMP Superseal
Number of pulses per revolutionN 48
Period accuracy ±3%
Phase shift output signal  90°
Tolerance phase shift output signal ±20°
Calculation data
Basic dynamic load ratingC 12.7kN
Basic static load ratingC0 6.55kN
Fatigue load limitPu 0.28kN
Limiting speed  10000r/min
Calculation factorkr 0.025
Calculation factorf0 13
Mass
Mass sensor unit  0.14kg
Appropriate products
Snap ring  SP 47
