SKF C4030K30V CARB toroidal roller bearings,SKF C 4030 K30V Roller bearings-BEARINGPOWER Co.,Ltd.
Bearings, units and housings -- Roller bearings -- CARB toroidal roller bearings -- CARB toroidal roller bearings -- SKF C 4030 K30V

C 4030 K30V

SKF Explorer
Dimensions
d 150mm
D 225mm
B 75mm
d2≈173mm
D1≈204mm
s1max.17.4mm
s2max.10.6mm
r1,2min.2.1mm

Tapered bore, taper 1:30

Abutment dimensions
Damax.214mm
ramax.2mm
    Calculation data
    Basic dynamic load ratingC 780kN
    Basic static load ratingC0 1320kN
    Fatigue load limitPu 127kN
    Limiting speed  750r/min
    Misalignment factork1 0.107
    Operating clearance factork2 0.106
    Mass
    Mass bearing  10.5kg
