Bearings, units and housings -- Super-precision bearings -- Angular contact thrust ball bearings for screw drives -- Angular contact thrust ball bearings for screw drives, cartridge units with a flanged housing, super-precision -- SKF FBSA 204/DB

FBSA 204/DB

Dimensions

d	20	mm
H	90	mm
A	47	mm
A₁	44.26	mm
A₂	32	mm
A₃	13	mm
d₁	26	mm
D₁	64	mm
D₂	60	mm
D₃	36	mm

Calculation data

Basic dynamic load rating	C	22	kN
Basic static load rating	C₀	49	kN
Fatigue load limit	P_u	1.8	kN
Attainable speed for preload class A		7600	r/min
Attainable speed for preload class B		3800	r/min
Preload class A		1480	kN
Preload class B		2960	kN
Frictional moment for preload class A		0.05	N·m
Frictional moment for preload class B		0.091	N·m
Static axial stiffnes for preload class A		680	N/µm
Static axial stiffnes for preload class B		860	N/µm

Mass

Mass cartridge unit

1.1

Mounting information

Through hole diameter for attachment bolts	N	6.6	mm
Pitch diameter of attachement bolt holes	J	76	mm
Cartridge half diameter without flange	J₁	32	mm

Model Number: FBSA 204/DB
Inner Diameter：20mm Outer Diameter：-mm Width：90mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Super-precision bearings Angular contact thrust ball bearings for screw drives Angular contact thrust ball bearings for screw drives, cartridge units with a flanged housing, super-precision
Details： Angular contact thrust ball bearings for screw drives, cartridge units with a flanged housing, super-precision
Update date：2026-06-25
Application:Security Equipment,large agricultural machinery,dynamic blood pressure,chamfering machine etc,machine tool spindle,vertical processing,Garment Accessories,stamping die,Rolling mill,medical equipment,Industrial Electromechanical
Similar models:6204/HR11QN 1204 EKTN9 W 6204 RNU 204 7204 BE-2RZP NJ 2204 ECP 1204 ETN9 32040 X GEZH 204 ES-2LS 1204 EKTN9 + H 204
BEARING POWER International Trading Co.,Ltd. specialize in FBSA204/DB products，there is large inventory of SKF FBSA 204/DB Angular contact thrust ball bearings for screw drives, cartridge units with a flanged housing, super-precision. We has been built up long-term cooperation with SKF company, could make a bulk order of the FBSA 204/DB Which SKF FBSA204/DB is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
