Bearings, units and housings -- Super-precision bearings -- Angular contact thrust ball bearings for screw drives -- Angular contact thrust ball bearings for screw drives, cartridge units with a flanged housing, super-precision -- SKF FBSA 209/QFC

FBSA 209/QFC

Dimensions

d	45	mm
H	165	mm
A	106	mm
A₁	102.74	mm
A₂	43.5	mm
A₃	17	mm
d₁	66	mm
D₁	128	mm
D₂	124	mm
D₃	76	mm

Calculation data

Basic dynamic load rating	C	73.4	kN
Basic static load rating	C₀	268	kN
Fatigue load limit	P_u	9.8	kN
Attainable speed for preload class A		3150	r/min
Attainable speed for preload class B		1575	r/min
Preload class A		7500	kN
Preload class B		15000	kN
Frictional moment for preload class A		0.46	N·m
Frictional moment for preload class B		1.04	N·m
Static axial stiffnes for preload class A		2580	N/µm
Static axial stiffnes for preload class B		3280	N/µm

Mass

Mass cartridge unit

9.4

Mounting information

Through hole diameter for attachment bolts	N	11.4	mm
Pitch diameter of attachement bolt holes	J	146	mm
Cartridge half diameter without flange	J₁	64	mm

Model Number: FBSA 209/QFC
Inner Diameter：45mm Outer Diameter：-mm Width：165mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Super-precision bearings Angular contact thrust ball bearings for screw drives Angular contact thrust ball bearings for screw drives, cartridge units with a flanged housing, super-precision
Details： Angular contact thrust ball bearings for screw drives, cartridge units with a flanged housing, super-precision
Update date：2026-06-25
Application:Reflective Materials Industrial fabrics,Insect Count,CNC,pipe fittings Steel industry,generator,Broadcasting System,cooling system,Industrial,hydraulic connector,air purification,knitted fabrics
Similar models:NJ 2209 ECNJ NJ 209 ECJ 7209 BEGAP 332096 E/C725 S7209 CD/HCP4A N 209 ECM 22209 EK W 6209-2RZ YAR 209-2RF 3209 A-2ZTN9/MT33
BEARING POWER International Trading Co.,Ltd. specialize in FBSA209/QFC products，there is large inventory of SKF FBSA 209/QFC Angular contact thrust ball bearings for screw drives, cartridge units with a flanged housing, super-precision. We has been built up long-term cooperation with SKF company, could make a bulk order of the FBSA 209/QFC Which SKF FBSA209/QFC is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
