Bearings, units and housings -- Bearing housings -- Split pillow blocks, SAF and SAW series (inch dimensions) -- SAF and SAW pillow blocks with bearings on an adapter sleeve -- SKF FSAF 22611

FSAF 22611

Dimensions

d_a		49.212	mm
D_a		120	mm
C_a		52.807	mm
A₁		79.375	mm
A₂		123.825	mm
S		4.763	mm
b_a		36.513	mm
H		157.162	mm
H₁		82.55	mm
H₂		30.163	mm
J	min.	206.375	mm
J	max.	241.3	mm
J₁		50.8	mm
L		279.4	mm
N₁		15.875	mm
Threaded holes
R₁		44.45	mm
R₂		25.4	mm
R_G		1/4 NPT
P_G		1/8 NPT
Oil level
h		36.513	mm

Included products

Housing			FSAF 611
Bearing			22311 EK
Adapter sleeve assembly			SNW 111x1.15/16
Stabilizing ring			SR-13-11
Labyrinth ring			2 x LER 24
Check availability of bearings with other clearance classes (e.g. C3)

Associated products

End plug (suffix Y)

EPR 5

Speed ratings

Bearing limiting speed

5600

r/min

Recommended safe loads

P_60°	35.6	kN
P_90°	21.4	kN
P_120°	13.3	kN
P_150°	12	kN
P_180°	14.2	kN
P_a	6.94	kN

Mass

Mass pillow block

14.1

Mounting information

Cap bolt		2 x 1/2-13 UNC
Cap bolt recommended tightening torque		149.1	N·m
Cap bolt, SAE grade		8
Appropriate attachment bolt size	G	0.5	in
Initial grease fill		68.04	g

Model Number: FSAF 22611
Inner Diameter：49.2125mm Outer Diameter：-mm Width：-mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Bearing housings Split pillow blocks, SAF and SAW series (inch dimensions) SAF and SAW pillow blocks with bearings on an adapter sleeve
Details： SAF and SAW pillow blocks with bearings on an adapter sleeve
Update date：2026-06-24
Application:power tools,Spectral Products,Laser Devices,municipal machinery,pump industry,chuck industry,Broadcasting System,trolley,climb ladder,Vertical pull,Industrial
Similar models:FSAF 22611 x 1.7/8 SAF 22611-210 FSAF 22611 x 1.7/8 T SAF 22611 x 1.7/8 T FSAF 22611 x 2 SAF 22611 x 2 SAF 22611 x 1.7/8 FSAF 22611 SAF 22611 SAF 22611 T
BEARING POWER International Trading Co.,Ltd. specialize in FSAF22611 products，there is large inventory of SKF FSAF 22611 SAF and SAW pillow blocks with bearings on an adapter sleeve. We has been built up long-term cooperation with SKF company, could make a bulk order of the FSAF 22611 Which SKF FSAF22611 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
