SKF FSAF22615x2.1/2T Split pillow blocks, SAF and SAW series (inch dimensions),SKF FSAF 22615 x 2.1/2 T Bearing housings-BEARINGPOWER Co.,Ltd.
Bearings, units and housings -- Bearing housings -- Split pillow blocks, SAF and SAW series (inch dimensions) -- SAF and SAW pillow blocks with bearings on an adapter sleeve -- SKF FSAF 22615 x 2.1/2 T

FSAF 22615 x 2.1/2 T

Dimensions
da 63.5mm
Da 160mm
Ca 64.795mm
A1 98.425mm
A2 223.838mm
S 4.763mm
ba 44.45mm
H 192.088mm
H1 101.6mm
H2 41.275mm
Jmin.263.525mm
Jmax.295.275mm
J1 53.975mm
L 349.25mm
N1 19.05mm
Threaded holes
R1 60.325mm
R2 27.94mm
RG 3/8 NPT
PG 1/8 NPT
Oil level
h 40.481mm
Included products
Housing
FSAF 615
Bearing
Adapter sleeve assembly
Stabilizing ring
SR-18-15
Taconite seal  TER 38
  • Check availability of bearings with other clearance classes (e.g. C3)
Associated products
End plug (suffix Y)
EPR 7
Speed ratings
Max. speed for Taconite seal  1250r/min
Recommended safe loads
P60° 101kN
P90° 60.9kN
P120° 38.3kN
P150° 34.7kN
P180° 42.3kN
Pa 12.5kN
Mass
Mass pillow block  23.6kg
Mounting information
Cap bolt
2 x 5/8-11 UNC
Cap bolt recommended tightening torque  298.3N·m
Cap bolt, SAE grade  8
Appropriate attachment bolt sizeG 0.625in
Initial grease fill  141.75g
