Bearings, units and housings -- Bearing housings -- Split plummer block housings, SNL and SE 2, 3, 5 and 6 series -- SNL series for bearings on an adapter sleeve, with oil seals -- SKF FSNL 617 TURU

FSNL 617 TURU

Appropriate products

Bearing (basic designation)			C 2317 K
Adapter sleeve			H 2317
Locating ring			2 x FRB 5/180
End cover			ASNH 520-617 R

Appertaining products

Housing			FSNL 520-617 RU
Oil seal			2 x TSN 617 U

Dimensions

d_a		75	mm
C_a		70	mm
D_a		180	mm
A₁		110	mm
A₂		181	mm
H		218	mm
H₁		112	mm
H₂		40	mm
J		320	mm
J₁		60	mm
L		380	mm
N		24	mm
N₁		18	mm
Dowel pins
J₆		348	mm
N₄	max.	8	mm

Breaking loads, housing

P_0°	470	kN
P_55°	620	kN
P_90°	370	kN
P_120°	280	kN
P_150°	250	kN
P_180°	310	kN
P_a	200	kN

Yield point, cap bolts

Q_120°	620	kN
Q_150°	360	kN
Q_180°	310	kN

Mass

Mass housing

17.6

Mounting information

Cap bolt, size		M 20x100
Cap bolt, rec. tightening torque		200	N·m
Appropriate attachment bolt, size	G	16	mm
Appropriate attachment bolt, rec. tightening torque		200	N·m
Oil level, min.		37	mm
Oil level, max.		46	mm

Model Number: FSNL 617 TURU
Inner Diameter：75mm Outer Diameter：-mm Width：-mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Bearing housings Split plummer block housings, SNL and SE 2, 3, 5 and 6 series SNL series for bearings on an adapter sleeve, with oil seals
Details： SNL series for bearings on an adapter sleeve, with oil seals
Update date：2026-06-24
Application:ventilation fans,Liposuction device,hook,intermediate,hanging clamp,Spectral Products,electromagnet,Animal Tracking,extruder,Industrial,food testing
Similar models:FSAF 22617 x 2.7/8 T FSAF 1617 x 3 TLC FSAF 22617 x 3 TLC W 61702-2RS1 SAF 1617 W 61705 R W 61700 R SAF 1617 T W 617/6 SAF 22617 x 2.7/8 TLC
BEARING POWER International Trading Co.,Ltd. specialize in FSNL617TURU products，there is large inventory of SKF FSNL 617 TURU SNL series for bearings on an adapter sleeve, with oil seals. We has been built up long-term cooperation with SKF company, could make a bulk order of the FSNL 617 TURU Which SKF FSNL617TURU is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
