Bearings, units and housings -- Bearing units -- Y-bearing units (ball bearing units) -- Y-bearing flanged units -- Y-bearing square flanged units SKF FY 1.1/2 LDW

FY 1.1/2 LDW

Housing material

Cast iron

Dimensions

d		38.1	mm
A		38.5	mm
A₁		14	mm
A₃	H14	3.2	mm
A₅		23.5	mm
B₁		42.9	mm
D_a	H11	115.9	mm
D_b1		98	mm
D_b2		106	mm
J		101.5	mm
L		130	mm
N		14	mm
s₁		25.9	mm
T		49.9	mm
Values for B₁ and s₁ before the grub screw is tightened (sleeve and inner ring bore at starting position).
Dowel pins
J₆		118	mm
J₇		34	mm
N₄		4	mm

Calculation data

Basic dynamic load rating	C	30.7	kN
Basic static load rating	C₀	19	kN
Fatigue load limit	P_u	0.8	kN
Limiting speed		950	r/min

Mass

Mass bearing unit

1.8

Mounting information

Thread grub screw	G₂	M6
Hexagonal key size for grub screw	N	3	mm
Recommended tightening torque for grub screw		7.4	N·m
Recommended diameter for attachment bolts, mm	G	12	mm
Recommended diameter for attachment bolts, inch	G	0.5	in
Appropriate SKF mounting kit		626830

Appertaining products

Housing			FY 508 M/VZ033
Bearing			YSPAG 208-108

Appropriate products

End cover

ECY 208

Model Number: FY 1.1/2 LDW
Inner Diameter：38.1mm Outer Diameter：-mm Width：-mm
Reference speed:950 r/min Limiting speed:-
Type：Bearings, units and housings Bearing units Y-bearing units (ball bearing units) Y-bearing flanged units
Details： Y-bearing flanged units Y-bearing square flanged units
