Bearings, units and housings -- Bearing units -- Y-bearing units (ball bearing units) -- Y-bearing flanged units -- Y-bearing square flanged units SKF FY 1.3/4 RM

FY 1.3/4 RM

Housing material

Cast iron

Dimensions

d		44.45	mm
A		39	mm
A₁		14	mm
A₃	H14	3.2	mm
A₅		26.5	mm
B		37	mm
D_a	H11	119.1	mm
D_b1		102	mm
D_b2		112	mm
J		105	mm
L		137	mm
N		16	mm
s₁		25.8	mm
T		49.8	mm
Threaded hole
R_G		1/4-28 UNF
R₁		24.5	mm
Grease fitting
D_N		6.5	mm
SW_N		7	mm
G_N		1/4-28 SAE-LT
Dowel pins
J₆		123	mm
J₇		33.5	mm
N₄		4	mm

Calculation data

Basic dynamic load rating	C	33.2	kN
Basic static load rating	C₀	21.6	kN
Fatigue load limit	P_u	0.915	kN
Limiting speed		4300	r/min

(with shaft tolerance h6)

Mass

Mass bearing unit

1.9

Mounting information

Thread grub screw	G₂	5/16-24 UNF
Hexagonal key size for grub screw	N	3.969	mm
Recommended tightening torque for grub screw		6.5	N·m
Recommended diameter for attachment bolts, mm	G	14	mm
Recommended diameter for attachment bolts, inch	G	0.5625	in

Appertaining products

Housing			FY 509 M
Bearing			YAT 209-112

Appropriate products

End cover

ECY 209

Model Number: FY 1.3/4 RM
Inner Diameter：44.45mm Outer Diameter：-mm Width：-mm
Reference speed:4300 r/min Limiting speed:-
Type：Bearings, units and housings Bearing units Y-bearing units (ball bearing units) Y-bearing flanged units
Details： Y-bearing flanged units Y-bearing square flanged units
