Bearings, units and housings -- Bearing units -- Y-bearing units (ball bearing units) -- Y-bearing flanged units -- Square flanged housings for Y-bearings SKF FY 509 M

FY 509 M

Material

Cast iron

Dimensions

D		85	mm
D_a	H11	119.1	mm
D_b1		102	mm
D_b2		112	mm
A		39	mm
A₁		14	mm
A₂		24	mm
A₃	H14	3.2	mm
A₅		23	mm
J		105	mm
L		137	mm
N		16	mm
Threaded hole
R_G		1/4-28 UNF
R₁		24.5	mm
Grease fitting
D_N		6.5	mm
SW_N		7	mm
G_N		1/4-28 SAE-LT
Dowel pins
J₆		123	mm
J₇		33.5	mm
N₄		4	mm

Mass

Mass housing

1.3

Mounting information

Recommended diameter for attachment bolts, mm	G		14	mm
Recommended diameter for attachment bolts, inch	G		0.5625	in

Appropriate products

End cover

ECY 209
