Bearings, units and housings -- Bearing units -- Y-bearing units (ball bearing units) -- Y-bearing flanged units -- Y-bearing square flanged units SKF FYJ 90 TF

FYJ 90 TF

Housing material

Cast iron

Dimensions

d		90	mm
A		63.5	mm
A₁		23	mm
A₃	H14	3.2	mm
B		89	mm
D_a	H11	193.7	mm
D_b1		187	mm
D_b2		201	mm
J		187	mm
L		235	mm
N		23	mm
s₁		54	mm
T		94	mm
Threaded hole
R_G		1/4-28 UNF
R₁		40	mm
Grease fitting
D_N		6.5	mm
SW_N		7	mm
G_N		1/4-28 SAE-LT
Dowel pins
J₆		207	mm
J₇		52.5	mm
N₄		4	mm

Calculation data

Basic dynamic load rating	C	95.6	kN
Basic static load rating	C₀	72	kN
Fatigue load limit	P_u	2.7	kN
Limiting speed		2000	r/min

(with shaft tolerance h6)

Mass

Mass bearing unit

10.6

Mounting information

Thread grub screw	G₂	M12x1.5
Hexagonal key size for grub screw	N	6	mm
Recommended tightening torque for grub screw		28.5	N·m
Recommended diameter for attachment bolts, mm	G	20	mm
Recommended diameter for attachment bolts, inch	G	0.75	in

Appertaining products

Housing			FYJ 518
Bearing			YAR 218-2F
