Bearings, units and housings -- Bearing units -- Y-bearing units (ball bearing units) -- Y-bearing flanged units -- Y-bearing oval flanged units SKF FYTB 1.1/2 FM

FYTB 1.1/2 FM

Housing material

Cast iron

Dimensions

d		38.1	mm
A		38.5	mm
A₁		14	mm
A₃	H14	3.2	mm
A₅		26	mm
B₁		43.2	mm
B₄		6.75	mm
D_a	H11	88.9	mm
D_b1		98	mm
D_b2		102	mm
J		143.5	mm
H		171.5	mm
L		102	mm
N		14	mm
s₁		32.7	mm
T		56.7	mm
Threaded hole
R_G		1/4-28 UNF
R₁		24.5	mm
R_a		45	°
Grease fitting
D_N		6.5	mm
SW_N		7	mm
G_N		1/4-28 SAE-LT
Dowel pins
J₆		115.5	mm
J₇		16	mm
N₄		2	mm

Calculation data

Basic dynamic load rating	C	30.7	kN
Basic static load rating	C₀	19	kN
Fatigue load limit	P_u	0.8	kN
Limiting speed		4800	r/min

(with shaft tolerance h6)

Mounting information

Thread grub screw	G₂	3/8-24 UNF
Hexagonal key size for grub screw	N	4.763	mm
Recommended tightening torque for grub screw		16.5	N·m
Recommended diameter for attachment bolts, mm	G	12	mm
Recommended diameter for attachment bolts, inch	G	0.5	in

Appertaining products

Housing			FYTB 508 M
Bearing			YET 208-108

Appropriate products

End cover

ECY 208

Model Number: FYTB 1.1/2 FM
Inner Diameter：38.1mm Outer Diameter：-mm Width：-mm
Reference speed:4800 r/min Limiting speed:-
Type：Bearings, units and housings Bearing units Y-bearing units (ball bearing units) Y-bearing flanged units
Details： Y-bearing flanged units Y-bearing oval flanged units
Update date：2026-06-24
Application:gear grinding machine,electronic components,wheel lathe,ventilation equipment,roller lathe,CNC,lifting tackle,Other Machine Tools,Display Devices,Industrial,sleep monitoring
Similar models:SSAFS 22640 x 7.1/4 TLC RNA 6910 61924 W 637/8-2Z PRMF 455045 248/900 CAK30MA/W20 2309 EKTN9 LR 8x12x10.5 YAR 210-2FW/VA228 7018 ACD/HCP4AL
BEARING POWER International Trading Co.,Ltd. specialize in FYTB1.1/2FM products，there is large inventory of SKF FYTB 1.1/2 FM Y-bearing flanged units. We has been built up long-term cooperation with SKF company, could make a bulk order of the FYTB 1.1/2 FM Which SKF FYTB1.1/2FM is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
