Bearings, units and housings -- Bearing units -- Y-bearing units (ball bearing units) -- Y-bearing flanged units -- Oval flanged housings for Y-bearings SKF FYTJ 506

FYTJ 506

Material

Cast iron

Dimensions

D		62	mm
D_a	H11	76.2	mm
D_b1		77	mm
D_b2		80	mm
A		30.5	mm
A₁		13.5	mm
A₂		18	mm
A₃	H14	3.2	mm
J		117	mm
H		148	mm
L		80	mm
N		16	mm
Threaded hole
R_G		1/4-28 UNF
R₁		19	mm
R_a		45	°
Grease fitting
D_N		6.5	mm
SW_N		7	mm
G_N		1/4-28 SAE-LT
Dowel pins
J₆		99	mm
J₇		12.5	mm
N₄		2	mm

Mass

Mass housing

0.57

Mounting information

Recommended diameter for attachment bolts, mm	G		14	mm
Recommended diameter for attachment bolts, inch	G		0.5625	in
