Coupling systems -- Flexible shaft couplings -- Flexible couplings with oil injection mounting, disc couplings -- -- SKF KDMS 604-385/180

KDMS 604-385/180

Dimensions

d_a		180	mm
D₁		290	mm
D₂		419.1	mm
D₃		254	mm
D₄		222.3	mm
L		365	mm
L₁		33.5	mm
L₂		34.5	mm
L₃		385	mm
s	min.	1.5	mm

Calculation data

Max. nominal application torque	74.6	kN·m
Max. speed	5600	r/min
Axial capacity	3.43	mm
Peak torque	149.1	kN·m
Stiffness	9.6	kN·m/mrad
Moment of inertia	4.92	kg·m²

Mass

Mass disc coupling

229

Model Number: KDMS 604-385/180
Inner Diameter：180mm Outer Diameter：419.1mm Width：-mm
Reference speed:- Limiting speed:-
Type：Coupling systems Flexible shaft couplings Flexible couplings with oil injection mounting, disc couplings
Details：
Update date：2025-12-16
Application:packing equipment,molding machine,Roller mill,security equipment,safety testing,pump industry,journal lathe,sleep monitoring,pipe fittings Steel industry,fabric products,natural instruments
Similar models:KDMS 604-385/180 KD21-604 KD10-604 KDMS 604-370/170
BEARING POWER International Trading Co.,Ltd. specialize in KDMS604-385/180 products，there is large inventory of SKF KDMS 604-385/180 . We has been built up long-term cooperation with SKF company, could make a bulk order of the KDMS 604-385/180 Which SKF KDMS604-385/180 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
