Bearings, units and housings -- Track rollers -- Cam followers -- Cam followers -- SKF KR 19 PPSKA

KR 19 PPSKA

Dimensions

D		19	mm
d		8	mm
B		32	mm
C		11	mm
B₁		20	mm
C₁		0.6	mm
d₁		15	mm
G		M 8
G₁		10	mm
SW		4	mm
r_1,2	min.	0.15	mm

Calculation data

Basic dynamic load rating	C	3.47	kN
Basic static load rating	C₀	3.8	kN
Fatigue load limit	P_u	0.415	kN
Maximum dynamic radial loads	F_r	3.8	kN
Maximum static radial loads	F_0r	5.5	kN
Limiting speed		5600	r/min

Mass

Mass cam follower

0.029

Mounting information

Recommended tighthening torque

N·m

Included products

Hexagonal nut

M 8x1.25

Model Number: KR 19 PPSKA
Inner Diameter：-mm Outer Diameter：19mm Width：32mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Track rollers Cam followers Cam followers
Details： Cam followers
Update date：2026-01-19
Application:metering pump,food sterilization,Machine tools,CNC,Rolling mill gear box,rock drilling machinery,crimping tools,Wire grinder,multi-knife lathe,static control,power tools
