Bearings, units and housings -- Track rollers -- Cam followers -- Cam followers -- SKF KRV 35 PPA

KRV 35 PPA

Dimensions

D		35	mm
d		16	mm
B		52	mm
C		18	mm
B₁		32.5	mm
B₂		8	mm
C₁		0.8	mm
d₁		27.6	mm
G		M 16x1.5
G₁		17	mm
M		6	mm
M₁		3	mm
SW		8	mm
r_1,2	min.	0.6	mm

Calculation data

Basic dynamic load rating	C	12.3	kN
Basic static load rating	C₀	23.2	kN
Fatigue load limit	P_u	2.7	kN
Maximum dynamic radial loads	F_r	14.6	kN
Maximum static radial loads	F_0r	20.8	kN
Limiting speed		2600	r/min

Mass

Mass cam follower

0.17

Mounting information

Recommended tighthening torque

N·m

Included products

Grease fitting			NIP A2x7.5
Hexagonal nut			M 16x1.5

Associated products

Lubrication adapter

AP 8

Model Number: KRV 35 PPA
Inner Diameter：-mm Outer Diameter：35mm Width：18mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Track rollers Cam followers Cam followers
Details： Cam followers
Update date：2026-06-25
Application:Energy saving energy saving energy saving energy saving energy saving energy saving energy saving energy saving energy saving energy saving energy saving,position switch,hydraulic control element,Doppler,supporting facilities,Broadcasting System,gantry processing,Animal Tracking,pressure control valve,Forging machine,small diesel generators
Similar models:NK 35/20 TN BGSB 358371 GEM 35 ESX-2LS PCM 353920 M SYJ 35 KF PCMF 353916 E W 635-2Z SAW 23544 x 7.7/8 FYK 35 TD SYNT 35 L
BEARING POWER International Trading Co.,Ltd. specialize in KRV35PPA products，there is large inventory of SKF KRV 35 PPA Cam followers. We has been built up long-term cooperation with SKF company, could make a bulk order of the KRV 35 PPA Which SKF KRV35PPA is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
