Bearings, units and housings -- Super-precision bearings -- Cylindrical roller bearings -- Cylindrical roller bearings, single row, super-precision -- SKF N 1011 KTN/HC5SP

N 1011 KTN/HC5SP

Dimensions
d 55mm
D 90mm
B 18mm
d1 68.2mm
E 81mm
r1,2min.1.1mm
r3,4min.0.6mm
smax.2.5mm

Tapered bore, taper 1:12

Abutment dimensions
damin.61.5mm
Damin.82mm
Damax.83.5mm
ramax.1mm
dn 79.8mm
Calculation data
Basic dynamic load ratingC 40.2kN
Basic static load ratingC0 48kN
Fatigue load limitPu 5.7kN
Attainable speed for grease lubrication  13000r/min
Attainable speed for oil-air lubrication  15000r/min
Reference grease quantityGref 4.4cm³
Static radial stiffness (guideline value)  810N/µm
Mass
Mass bearing  0.35kg
