Bearings, units and housings -- Roller bearings -- Cylindrical roller bearings -- Single row cylindrical roller bearings -- Cylindrical roller bearings, single row SKF NUP 232 ECML

NUP 232 ECML

SKF Explorer
Dimensions
d 160mm
D 290mm
B 48mm
d1≈206mm
D1≈249.6mm
F 195mm
r1,2min.3mm
r3,4min.3mm
Abutment dimensions
damin.175mm
dbmin.210mm
Damax.274.2mm
ramax.2.5mm
Calculation data
Basic dynamic load ratingC 585kN
Basic static load ratingC0 680kN
Fatigue load limitPu 72kN
Reference speed  2400r/min
Limiting speed  4000r/min
Calculation factorkr 0.23
Limiting valuee 0.2
Axial load factorY 0.6
Mass
Mass bearing  15.1kg
