Bearings, units and housings -- Plain bearings -- Bushings, thrust washers and strips -- Bushings -- SKF PCMF 060808 E
PCMF 060808 E
Dimensions
| d | 6 | mm | |
| D | 8 | mm | |
| B | 8 | mm | |
| D1 | 12 | mm | |
| B1 | 1 | mm | |
| c1 | min. | 0.1 | mm |
| c1 | max. | 0.7 | mm |
| c2 | min. | 0.2 | mm |
| c2 | max. | 1 | mm |
| a | ±8 | 20 | ° |
| r | max. | 1 | mm |
Recommended fits
| Tolerance shaft | f7 | |||
| Tolerance housing | H7 | |||
Calculation data
| Basic dynamic load rating - radial direction | C | 2.9 | kN | |
| Basic static load rating - radial direction | C0 | 9 | kN | |
| Basic dynamic load rating - axial direction | Ca | 2.75 | kN | |
| Basic static load rating - axial direction | C0a | 8.65 | kN | |
| Specific dynamic load factor | K | 80 | N/mm² | |
| Specific static load factor | K0 | 250 | N/mm² | |
| Factor depending on material and bearing type | KM | 480 | ||
| Permissible sliding velocity | v | min. | 0 | m/s |
| Permissible sliding velocity | v | max. | 2 | m/s |
| Coefficient of friction | µ | min. | 0.03 | |
| Coefficient of friction | µ | max. | 0.25 |
Mass
| Mass bushing | 0.0019 | kg |
