Bearings, units and housings -- Bearing housings -- Split pillow blocks, SAF and SAW series (inch dimensions) -- SAF and SAW pillow blocks with bearings on an adapter sleeve -- SKF SAF 1616 T

SAF 1616 T

Dimensions

d_a		68.263	mm
D_a		170	mm
C_a		67.793	mm
A₁		98.425	mm
A₂		233.363	mm
b_a		36.513	mm
H		209.55	mm
H₁		107.95	mm
H₂		44.45	mm
J	min.	269.875	mm
J	max.	320.675	mm
L		361.95	mm
N₁		22.225	mm
Threaded holes
R₁		63.5	mm
R₂		26.988	mm
R_G		3/8 NPT
P_G		1/8 NPT
Oil level
h		46.038	mm

Included products

Housing			SAF 616
Bearing			1316 K
Adapter sleeve assembly			SNW 16x2.11/16
Stabilizing ring			2 x SR-1616
Taconite seal			TER 44
Check availability of bearings with other clearance classes (e.g. C3); Stabilizing ring(s) not included

Associated products

End plug (suffix Y)

EPR 8

Speed ratings

Max. speed for Taconite seal

1150

r/min

Recommended safe loads

P_60°	85.9	kN
P_90°	51.6	kN
P_120°	32	kN
P_150°	28.9	kN
P_180°	34.7	kN
P_a	9.43	kN

Mass

Mass pillow block

29.8

Mounting information

Cap bolt		2 x 3/4-10 UNC
Cap bolt recommended tightening torque		515.2	N·m
Cap bolt, SAE grade		8
Appropriate attachment bolt size	G	0.75	in
Initial grease fill		365.71	g

Model Number: SAF 1616 T
Inner Diameter：68.2625mm Outer Diameter：-mm Width：-mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Bearing housings Split pillow blocks, SAF and SAW series (inch dimensions) SAF and SAW pillow blocks with bearings on an adapter sleeve
Details： SAF and SAW pillow blocks with bearings on an adapter sleeve
Update date：2026-06-24
Application:tower crane,gear grinding machine,ultra-quiet generators,large agricultural machinery,Laser Measurements,Food testing,training beds etc,power protection,other rubber,sucker industry,Flame Cutting
Similar models:SAF 1616 SAF 1616 x 2.5/8 T SAF 1616 x 2.5/8 TLC SAF 1616 x 2.5/8 BK 1616 HK 1616.2RS FSAF 1616 T SAF 1616 x 2.3/4 T SAF 1616 TLC PCZ 1616 M
BEARING POWER International Trading Co.,Ltd. specialize in SAF1616T products，there is large inventory of SKF SAF 1616 T SAF and SAW pillow blocks with bearings on an adapter sleeve. We has been built up long-term cooperation with SKF company, could make a bulk order of the SAF 1616 T Which SKF SAF1616T is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
