Bearings, units and housings -- Bearing housings -- Split pillow blocks, SAF and SAW series (inch dimensions) -- SAF and SAW pillow blocks with bearings on an adapter sleeve -- SKF SAF 23032 KAT x 5.1/2

SAF 23032 KAT x 5.1/2

Dimensions

d_a		139.7	mm
D_a		240	mm
C_a		89.789	mm
A₁		133.35	mm
A₂		277.813	mm
b_a		59.531	mm
H		287.337	mm
H₁		152.4	mm
H₂		60.325	mm
J	min.	371.475	mm
J	max.	406.4	mm
J₁		82.55	mm
L		466.725	mm
N₁		25.4	mm
Threaded holes
R₁		79.375	mm
R₂		36.513	mm
R_G		1/2 NPT
P_G		1/4 NPT
Oil level
h		51.594	mm

Included products

Housing			SAF 032 KA
Bearing			23032 CCK/W33
Adapter sleeve assembly			SNW 3032x5.1/2
Stabilizing ring			2 x 38151-32
Taconite seal			TER 131
Check availability of bearings with other clearance classes (e.g. C3); Stabilizing ring(s) not included

Associated products

End plug (suffix Y)

EPR 16

Speed ratings

Max. speed for Taconite seal

560

r/min

Recommended safe loads

P_60°	189	kN
P_90°	113	kN
P_120°	73.8	kN
P_150°	68.1	kN
P_180°	84.5	kN
P_a	25.4	kN

Mass

Mass pillow block

79.7

Mounting information

Cap bolt		2 x 1-8 UNC
Cap bolt recommended tightening torque		1220	N·m
Cap bolt, SAE grade		8
Appropriate attachment bolt size	G	0.875	in
Initial grease fill		382.73	g

Model Number: SAF 23032 KAT x 5.1/2
Inner Diameter：139.7mm Outer Diameter：-mm Width：-mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Bearing housings Split pillow blocks, SAF and SAW series (inch dimensions) SAF and SAW pillow blocks with bearings on an adapter sleeve
Details： SAF and SAW pillow blocks with bearings on an adapter sleeve
