Bearings, units and housings -- Bearing housings -- Split pillow blocks, SAF and SAW series (inch dimensions) -- SAF and SAW pillow blocks with bearings on an adapter sleeve -- SKF SAF 23034 KAT x 6

SAF 23034 KAT x 6

Dimensions

d_a		150.813	mm
D_a		259.999	mm
C_a		86.614	mm
A₁		149.225	mm
A₂		261.938	mm
b_a		64.294	mm
H		305.594	mm
H₁		152.4	mm
H₂		60.325	mm
J	min.	396.875	mm
J	max.	441.325	mm
J₁		85.725	mm
L		511.175	mm
N₁		28.575	mm
Threaded holes
R₁		87.313	mm
R₂		38.1	mm
R_G		3/4 NPT
P_G		1/4 NPT
Oil level
h		43.656	mm

Included products

Housing			SAF 034 KA
Bearing			23034 CCK/W33
Adapter sleeve assembly			SNW 3034x6
Stabilizing ring			2 x SR-0-24
Taconite seal			TER 141
Check availability of bearings with other clearance classes (e.g. C3); Stabilizing ring(s) not included

Associated products

End plug (suffix Y)

EPR 18

Speed ratings

Max. speed for Taconite seal

520

r/min

Recommended safe loads

P_60°	249	kN
P_90°	149	kN
P_120°	94.3	kN
P_150°	85.9	kN
P_180°	103	kN
P_a	34	kN

Mass

Mass pillow block

63.9

Mounting information

Cap bolt		2 x 1-8 UNC
Cap bolt recommended tightening torque		799.9	N·m
Cap bolt, SAE grade		5
Eye bolt		3/8-16 UNC
Appropriate attachment bolt size	G	1	in
Initial grease fill		481.95	g

Model Number: SAF 23034 KAT x 6
Inner Diameter：150.8125mm Outer Diameter：-mm Width：-mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Bearing housings Split pillow blocks, SAF and SAW series (inch dimensions) SAF and SAW pillow blocks with bearings on an adapter sleeve
Details： SAF and SAW pillow blocks with bearings on an adapter sleeve
Update date：2026-06-24
Application:metering pump,food sterilization,Machine tools,CNC,Rolling mill gear box,rock drilling machinery,crimping tools,Wire grinder,multi-knife lathe,static control,power tools
Similar models:SAF 23034 KA x 5.7/8 SSAFS 23034 KA x 5.7/8 SSAFS 23034 KAT x 6 SAFS 23034 KAT x 5.7/8 SAFS 23034 KAT x 5.13/16 SAF 23034 KA x 5.15/16 SSAFS 23034 KATLC x 6 SAFS 23034 KA x 5.13/16 SAFS 23034 KA x 5.15/16 SAF 23034 KAT x 5.13/16
BEARING POWER International Trading Co.,Ltd. specialize in SAF23034KATx6 products，there is large inventory of SKF SAF 23034 KAT x 6 SAF and SAW pillow blocks with bearings on an adapter sleeve. We has been built up long-term cooperation with SKF company, could make a bulk order of the SAF 23034 KAT x 6 Which SKF SAF23034KATx6 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
