SKF SAF23038KATLCx6.13/16 Split pillow blocks, SAF and SAW series (inch dimensions),SKF SAF 23038 KATLC x 6.13/16 Bearing housings-BEARINGPOWER Co.,Ltd.
Bearings, units and housings -- Bearing housings -- Split pillow blocks, SAF and SAW series (inch dimensions) -- SAF and SAW pillow blocks with bearings on an adapter sleeve -- SKF SAF 23038 KATLC x 6.13/16

SAF 23038 KATLC x 6.13/16

Dimensions
da 174.625mm
Da 289.999mm
Ca 89.789mm
A1 158.75mm
A2 222.25mm
ba 69.85mm
H 336.55mm
H1 169.875mm
H2 66.675mm
Jmin.441.325mm
Jmax.488.95mm
J1 95.25mm
L 558.8mm
N1 28.575mm
Threaded holes
R1 104.775mm
R2 33.337mm
RG 3/4 NPT
PG 1/4 NPT
Oil level
h 47.625mm
Included products
Housing
SAF 038 KA
Bearing
Adapter sleeve assembly
Stabilizing ring
2 x 38151-38
Labyrinth ring
2 x LOR 153
PosiTrac Plus contact element
2 x B10724-155
  • Check availability of bearings with other clearance classes (e.g. C3); Stabilizing ring(s) not included
Associated products
End plug (suffix Y)
EPR 21
Speed ratings
Max. speed for PosiTrac Plus seal  825r/min
Recommended safe loads
P60° 226kN
P90° 136kN
P120° 85.9kN
P150° 78.3kN
P180° 94.3kN
Pa 40kN
Mass
Mass pillow block  90.7kg
Mounting information
Cap bolt
4 x 3/4-10 UNC
Cap bolt recommended tightening torque  359.3N·m
Cap bolt, SAE grade  5
Eye bolt
2 x 3/8-16 UNC
Appropriate attachment bolt sizeG 1in
Initial grease fill  793.8g
