Bearings, units and housings -- Bearing housings -- Split pillow blocks, SAF and SAW series (inch dimensions) -- SAF and SAW pillow blocks with bearings on an adapter sleeve -- SKF SAFS 22526 T

SAFS 22526 T

Dimensions

d_a		112.713	mm
D_a		230	mm
C_a		73.812	mm
A₁		130.175	mm
A₂		269.875	mm
S		4.763	mm
b_a		57.944	mm
H		292.1	mm
H₁		152.4	mm
H₂		60.325	mm
J	min.	371.475	mm
J	max.	406.4	mm
J₁		82.55	mm
L		466.725	mm
N₁		23.813	mm
Threaded holes
R₁		79.375	mm
R₂		36.513	mm
R_G		1/2 NPT
P_G		1/4 NPT
Oil level
h		60.325	mm

Included products

Housing			SAFS 526
Bearing			22226 EK
Adapter sleeve assembly			SNW 26x4.7/16
Stabilizing ring			SR-26-0
Taconite seal			TER 117
Check availability of bearings with other clearance classes (e.g. C3)

Associated products

End plug (suffix Y)

EPR 15

Speed ratings

Max. speed for Taconite seal

700

r/min

Recommended safe loads

P_60°	189	kN
P_90°	113	kN
P_120°	73.8	kN
P_150°	68.1	kN
P_180°	84.5	kN
P_a	24.9	kN

Mass

Mass pillow block

83.9

Mounting information

Cap bolt		4 x 1-8 UNC
Cap bolt recommended tightening torque		799.9	N·m
Cap bolt, SAE grade		5
Eye bolt		2 x 3/8-16 UNC
Appropriate attachment bolt size	G	0.875	in
Initial grease fill		382.73	g

Model Number: SAFS 22526 T
Inner Diameter：112.7125mm Outer Diameter：-mm Width：-mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Bearing housings Split pillow blocks, SAF and SAW series (inch dimensions) SAF and SAW pillow blocks with bearings on an adapter sleeve
Details： SAF and SAW pillow blocks with bearings on an adapter sleeve
Update date：2026-06-24
Application:plastic molding,training beds etc,Technical Equipment,car shock absorber,enzyme,wire industry,labor insurance,Other machinery,medical equipment,Hair styling device,electromagnet
Similar models:SAF 22526 T SAF 22526 x 4.3/8 SAFS 22526 x 4.3/8 T SAF 22526 TLC SSAFS 22526 x 4.3/8 SAFS 22526 T SSAFS 22526 x 4.3/8 T SSAFS 22526 T SAF 22526 x 4.1/2 SAF 22526 x 4.1/2 TLC
BEARING POWER International Trading Co.,Ltd. specialize in SAFS22526T products，there is large inventory of SKF SAFS 22526 T SAF and SAW pillow blocks with bearings on an adapter sleeve. We has been built up long-term cooperation with SKF company, could make a bulk order of the SAFS 22526 T Which SKF SAFS22526T is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
