Bearings, units and housings -- Bearing housings -- Split plummer block housings, SNL and SE 2, 3, 5 and 6 series -- SNL and SE series for bearings on a cylindrical seat, with standard seals -- SKF SE 515-612

SE 515-612

Appropriate products

Bearing (basic designation)			C 2215
Lock nut			KMFE 15
Locating ring			2 x FRB 12.5/130

Dimensions

d_a		75	mm
d_b		85	mm
C_a		56	mm
D_a		130	mm
D_b		87	mm
A		115	mm
A₁		80	mm
H		156	mm
H₁		80	mm
H₂		30	mm
J		230	mm
L		280	mm
N		24	mm
N₁		18	mm
Dowel pins
J₆		257	mm
J₇		29	mm
N₄	max.	8	mm

Appropriate seals and end cover

4 x FS 170

ASNH 515-612

Breaking loads, housing

P_0°	290	kN
P_55°	410	kN
P_90°	250	kN
P_120°	185	kN
P_150°	160	kN
P_180°	205	kN
P_a	135	kN

Yield point, cap bolts

Q_120°	220	kN
Q_150°	125	kN
Q_180°	110	kN

Mass

Mass housing

8.57

Mounting information

Cap bolt, size		M 12x70
Cap bolt, rec. tightening torque		80	N·m
Appropriate attachment bolt, size	G	16	mm
Appropriate attachment bolt, rec. tightening torque		200	N·m
Initial grease fill, 20%		120	g
Initial grease fill, 40%		210	g

Model Number: SE 515-612
Inner Diameter：75mm Outer Diameter：-mm Width：-mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Bearing housings Split plummer block housings, SNL and SE 2, 3, 5 and 6 series SNL and SE series for bearings on a cylindrical seat, with standard seals
Details： SNL and SE series for bearings on a cylindrical seat, with standard seals
