Bearings, units and housings -- Plain bearings -- Spherical plain bearings and rod ends -- Rod ends with a female thread -- SKF SIL 25 ESX-2LS

SIL 25 ESX-2LS

SKF Explorer

Dimensions

d		25	mm
d₂	max.	65	mm
B		20	mm
G	6H	M 24x2
C₁	max.	18	mm
h₁		94	mm
a		7	°
d_k		35.5	mm
d₄	≈	35	mm
l₃	min.	36	mm
l₄	max.	128	mm
l₅	≈	18	mm
l₇	min.	30	mm
w	h14	30	mm
r₁	min.	0.6	mm

Calculation data

Basic dynamic load rating	C	72	kN
Basic static load rating	C₀	90	kN
Specific dynamic load factor	K	150	N/mm²
Material constant	K_M	330

Mass

Mass rod end

0.65

Model Number: SIL 25 ESX-2LS
Inner Diameter：25mm Outer Diameter：-mm Width：20mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Plain bearings Spherical plain bearings and rod ends Rod ends with a female thread
Details： Rod ends with a female thread
Update date：2026-06-24
Application:gantry processing,roller lathe,Cylinder Pneumatic Treatment Element,luminescent reagent,forming machine,Storage Device,Pneumatic Control Valves,medical Equipment,Hydraulic Equipment,thread processing machine,electromyography machine
Similar models:IR 25x30x20.5 SAF 22509 x 1.3/8 SSAFS 22534 x 5.7/8 SAFS 22520 TLC FSAF 22520 x 3.3/8 NK 25/20 SAFS 22517 T SILQG 125 ES SAF 22526 x 4.3/8 T SYK 25 LD
BEARING POWER International Trading Co.,Ltd. specialize in SIL25ESX-2LS products，there is large inventory of SKF SIL 25 ESX-2LS Rod ends with a female thread. We has been built up long-term cooperation with SKF company, could make a bulk order of the SIL 25 ESX-2LS Which SKF SIL25ESX-2LS is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
