Bearings, units and housings -- Plain bearings -- Spherical plain bearings and rod ends -- Rod ends with a female thread -- SKF SIQG 200 ES

SIQG 200 ES

Dimensions

d		200	mm
d₂	max.	420	mm
B		200	mm
G	6H	M 160x4
C₁	max.	164	mm
h₁		390	mm
a		4	°
d_k		250	mm
d₄	max.	221	mm
l₃	min.	161	mm
l₄	max.	623	mm
l₇	min.	193	mm
N	max.	323	mm
N₁	max.	106	mm
r₁	min.	1.1	mm

Bolts with internal hexagon

Size bolt with internal hexagon			M 30
Tightening torque bolt with internal hexagon			1350	N·m

Calculation data

Basic dynamic load rating	C	2120	kN
Basic static load rating	C₀	3400	kN
Specific dynamic load factor	K	100	N/mm²
Material constant	K_M	330

Mass

Mass rod end

165

Model Number: SIQG 200 ES
Inner Diameter：200mm Outer Diameter：-mm Width：200mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Plain bearings Spherical plain bearings and rod ends Rod ends with a female thread
Details： Rod ends with a female thread
Update date：2026-06-24
Application:Hydraulic Hose,historical instruments,ventilation fans,decoration machinery,Industrial,other mold,supporting facilities,Anesthetic Equipment,Pest Monitoring,metal mold,Other Machine Tools
Similar models:YET 211-200 YAR 211-200-2FW/VA228 PWM 180200150 PCMS 2005002.5 E 6200-ZNR S7200 ACD/P4A 3200 A-2ZTN9/MT33 PBM 180200100 M1G1 316200 GEZM 200 ES-2RS
BEARING POWER International Trading Co.,Ltd. specialize in SIQG200ES products，there is large inventory of SKF SIQG 200 ES Rod ends with a female thread. We has been built up long-term cooperation with SKF company, could make a bulk order of the SIQG 200 ES Which SKF SIQG200ES is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
