Bearings, units and housings -- Bearing housings -- Split plummer block housings, SNL 30, 31 and 32 series -- Large SNL series for bearings on an adapter sleeve, with standard seals -- SKF SNL 30/530

SNL 30/530

Appropriate products

Bearing (basic designation)			230/530 K
Adapter sleeve			OH 30/530 H
Locating ring			2 x FRB 31.5/780

Dimensions

d_a		500	mm
d₂		645	mm
C_a		248	mm
D_a		780	mm
A		470	mm
A₁		440	mm
A_TS		480	mm
A_TK		600	mm
H		920	mm
H₁		460	mm
H₂		155	mm
J		1110	mm
J₁		260	mm
L		1330	mm
N		70	mm
N₁		56	mm
s		35	mm
Shaft end
b_a	min.	188	mm
b_a	max.	243	mm
b_b		182.5	mm
b_c		248.5	mm
Dowel pins
J₆		1210	mm
N₄	max.	40	mm

Appropriate seals and end cover

Labyrinth seal			2 x TS 530
Taconite seal			2 x TK 30/530
End cover			ETS 530

Breaking loads, housing

P_0°	8800	kN
P_55°	11200	kN
P_90°	5400	kN
P_120°	4000	kN
P_150°	3500	kN
P_180°	4400	kN

Yield point, cap bolts

Q_120°	5800	kN
Q_150°	3350	kN
Q_180°	2900	kN

Mass

Mass housing

941

Mounting information

Cap bolt, size		M 42x320
Cap bolt, rec. tightening torque		850	N·m
Appropriate attachment bolt, size	G	48	mm
Appropriate attachment bolt, rec. tightening torque		5450	N·m
Eye bolt, size		2 x M 48
Initial grease fill, 20%		13	kg
Initial grease fill, 40%		21.5	kg

Model Number: SNL 30/530
Inner Diameter：500mm Outer Diameter：-mm Width：-mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Bearing housings Split plummer block housings, SNL 30, 31 and 32 series Large SNL series for bearings on an adapter sleeve, with standard seals
Details： Large SNL series for bearings on an adapter sleeve, with standard seals
