Bearings, units and housings -- Bearing housings -- Split plummer block housings, SNLN 30 series -- SNLN 30 series for bearings on a cylindrical seat -- SKF SNLN 3024

SNLN 3024

Appropriate products

Bearing			C 4024-2CS5V/GEM9
Lock nut			KMFE 24
Locating ring			2 x FRB 5/180

Dimensions

d_a		120	mm
d_b		135	mm
C_a		70	mm
D_a		180	mm
A		160	mm
A₁		110	mm
H		218	mm
H₁		112	mm
H₂		40	mm
J		320	mm
L		380	mm
N		32	mm
N₁		26	mm
Shaft end
b_a		48	mm
b_c		70	mm
Dowel pins
J₆		348	mm
J₇		39	mm
N₄	max.	8	mm
Seal stand-out
A_2L		10	mm
A_2T		45	mm

Appropriate seals and end cover

TSN 224 L

TSN 224 A

2 x TSN 224 S

2 x TSN 224 ND

ASNH 524-620

Breaking loads, housing

P_55°	520	kN
P_90°	310	kN
P_120°	230	kN
P_150°	210	kN
P_180°	260	kN
P_a	90	kN

Yield point, cap bolts

Q_120°	620	kN
Q_150°	360	kN
Q_180°	310	kN

Mass

Mass housing

17.5

Mounting information

Cap bolt, size		M 20 x 100
Cap bolt, rec. tightening torque		200	N·m
Appropriate attachment bolt, size	G	24	mm
Appropriate attachment bolt, rec. tightening torque		665	N·m
Initial grease fill, 20%		250	g
Initial grease fill, 40%		450	g

Model Number: SNLN 3024
Inner Diameter：120mm Outer Diameter：-mm Width：-mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Bearing housings Split plummer block housings, SNLN 30 series SNLN 30 series for bearings on a cylindrical seat
Details： SNLN 30 series for bearings on a cylindrical seat
Update date：2026-06-25
