Bearings, units and housings -- Bearing housings -- Split pillow blocks, SAF and SAW series (inch dimensions) -- SAF and SAW pillow blocks with bearings with a cylindrical bore -- SKF SSAFS 22240 T

SSAFS 22240 T

Dimensions

d_a	200	mm
d_b	222.25	mm
d_c	193.675	mm
D_a	359.999	mm
C_a	107.798	mm
A₁	203.2	mm
A₂	374.65	mm
S	4.763	mm
b_a	83.344	mm
H	419.1	mm
H₁	209.55	mm
H₂	85.725	mm
L	749.3	mm
Threaded holes
R₁	122.237	mm
R₂	42.862	mm
R_G	1 NPT
P_G	1/4 NPT
Oil level
h	62.706	mm

Included products

Housing			SSAFS 240
Bearing			22240 CC/W33
Check availability of other clearance classes (e.g. C3)
Lock nut			AN 40
Lock washer			W 40
Stabilizing ring			SR-40-34
Taconite seal (d_b shaft position)			TER 175
Taconite seal (d_c shaft position)			TER 164

Associated products

End plug (suffix Y)

EPR 22

Speed ratings

Max. speed for Taconite seal

350

r/min

Recommended safe loads

P_60°	364	kN
P_90°	218	kN
P_120°	136	kN
P_150°	120	kN
P_180°	145	kN
P_a	93.9	kN

Mass

Mass pillow block

254

Mounting information

Cap bolt	4 x 7/8-9 UNC
Cap bolt recommended tightening torque	528.8	N·m
Cap bolt, SAE grade	5
Eye bolt	2 x 3/8-16 UNC
Initial grease fill	2154.6	g

Model Number: SSAFS 22240 T
Inner Diameter：200mm Outer Diameter：-mm Width：-mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Bearing housings Split pillow blocks, SAF and SAW series (inch dimensions) SAF and SAW pillow blocks with bearings with a cylindrical bore
Details： SAF and SAW pillow blocks with bearings with a cylindrical bore
Update date：2026-06-24
Application:journal lathe,scientific instruments,industrial fans,printing machinery,Technical Equipment,Medium and large motor,dye pigments,mathematical instruments,rolling machine,switch,Vacuum generator
Similar models:22240 CC/W33 SAFS 22240 TLC SAFS 22240 T 22240-2CS5K/VT143 22240-2CS5/VT143 SAF 22240 SAF 22240 T SSAFS 22240 T SSAFS 22240 TLC BD-22240 CCK/W33-H 3140
