Bearings, units and housings -- Bearing units -- Y-bearing units (ball bearing units) -- Y-bearing plummer block units -- Y-bearing short base plummer block units SKF SYF 25 TF

SYF 25 TF

Housing material

Cast iron

Dimensions

d	25	mm
A	36	mm
A₁	22	mm
B	34.1	mm
H	70	mm
H₁	36.5	mm
J	50.8	mm
L	70	mm
s₁	19.8	mm
Threaded hole
R_G	1/4-28 UNF
R₁	2	mm
R_a	45	°
Grease fitting
D_N	6.5	mm
SW_N	7	mm
G_N	1/4-28 SAE-LT

Calculation data

Basic dynamic load rating	C	14	kN
Basic static load rating	C₀	7.8	kN
Fatigue load limit	P_u	0.335	kN
Limiting speed		7000	r/min

(with shaft tolerance h6)

Mass

Mass bearing unit

0.54

Mounting information

Housing thread for attachment bolts	G	M10
Thread length	G₁	15	mm
Hexagonal key size for grub screw	N	3	mm
Recommended tightening torque for grub screw		4	N·m

Appertaining products

Housing			SYF 505
Bearing			YAR 205-2F

Model Number: SYF 25 TF
Inner Diameter：25mm Outer Diameter：-mm Width：-mm
Reference speed:7000 r/min Limiting speed:-
Type：Bearings, units and housings Bearing units Y-bearing units (ball bearing units) Y-bearing plummer block units
Details： Y-bearing plummer block units Y-bearing short base plummer block units
Update date：2026-06-25
Application:relay,experimental equipment,beverage production,Small air generators,Industrial,knitted fabrics,Gripper Swing,extruder,tapered grinder,disposable,ship special
Similar models:SSAFS 22540 x 7.1/8 FSAF 22520 x 3.5/16 TLC NKI 60/25 SAF 22520 TLC SAFS 22526 x 4.3/8 T NX 25 Z SNL 3256 SAF 22516 SIR 25 ES SYFWR 25 YTHR
BEARING POWER International Trading Co.,Ltd. specialize in SYF25TF products，there is large inventory of SKF SYF 25 TF Y-bearing plummer block units. We has been built up long-term cooperation with SKF company, could make a bulk order of the SYF 25 TF Which SKF SYF25TF is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
