Bearings, units and housings -- Bearing units -- Roller bearing units -- Metric roller bearing units, SYNT and FYNT series (SKF ConCentra) -- Roller bearing plummer block units, for metric shafts SKF SYNT 60 FTF

SYNT 60 FTF

Dimensions

d_a		60	mm
A		80	mm
B		71	mm
H		151	mm
H₁		80	mm
H₂		30	mm
J		230	mm
L		275	mm
N		24	mm
N₁		18	mm
Shaft end
A₃		73	mm
A₅		35.5	mm
b_a	min.	38	mm
b_a	max.	65	mm
Dowel pins
J₆		254	mm
J₇		29	mm
N₄	max.	8	mm

Calculation data

Basic dynamic load rating	C	156	kN
Basic static load rating	C₀	166	kN
Fatigue load limit	P_u	18.6	kN
Limiting speed		1450	r/min
Calculation factor	e	0.24
Calculation factor	Y₁	2.8
Calculation factor	Y₂	4.2
Bearing mean diameter	d_m	85	mm
Basic bearing designation		22212 E

Load carrying ability

Breaking loads
P_0°	270	kN
P_55°	365	kN
P_90°	220	kN
P_120°	150	kN
P_150°	130	kN
P_180°	170	kN
Axial holding power
P_a	15	kN

Mass

Mass bearing unit

7.7

Mounting information

Attachment bolt diameter	G	16	mm
Tightening torque for attachment bolts		200	N·m
Grub screws		3 x M 6
Tightening torque for grub screws		8	N·m
Grease quantity for relubrication		6	g

Appropriate products

End cover

ECY 212

Model Number: SYNT 60 FTF
Inner Diameter：60mm Outer Diameter：-mm Width：-mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Bearing units Roller bearing units Metric roller bearing units, SYNT and FYNT series (SKF ConCentra)
Details： Metric roller bearing units, SYNT and FYNT series (SKF ConCentra) Roller bearing plummer block units, for metric shafts
