Bearings, units and housings -- Bearing units -- Y-bearing units (ball bearing units) -- Y-bearing take-up units -- Y-bearing take-up units SKF TUJ 40 TF

TUJ 40 TF

Housing material

Cast iron

Dimensions

d	40	mm
A	49	mm
A₁	16	mm
A₂	33	mm
B	49.2	mm
H	115	mm
H₁	102	mm
H₂	83	mm
L	145	mm
L₁	88	mm
L₂	15	mm
L₃	83	mm
N	29	mm
N₁	19	mm
N₂	50	mm
s₁	30.2	mm
Threaded hole
R_G	1/4-28 UNF
R₁	4	mm
R_a	30	°
Grease fitting
D_N	6.5	mm
SW_N	7	mm
G_N	1/4-28 SAE-LT

Calculation data

Basic dynamic load rating	C	30.7	kN
Basic static load rating	C₀	19	kN
Fatigue load limit	P_u	0.8	kN
Limiting speed with shaft tolerance h6		4800	r/min

Mass

Mass bearing unit

2.25

Mounting information

Grub (set) screw	G₂	M8x1
Hexagonal key size for grub screw	N	4	mm
Recommended tightening torque for grub screw		6.5	N·m

Appertaining products

Housing			TUJ 508
Bearing			YAR 208-2F

Model Number: TUJ 40 TF
Inner Diameter：40mm Outer Diameter：-mm Width：-mm
Reference speed:4800 r/min Limiting speed:-
