Coupling systems -- Flexible shaft couplings -- Flexible couplings with oil injection mounting, gear couplings -- -- SKF XHCE 040/OK 110

XHCE 040/OK 110

Dimensions

d_a		110	mm
A		242	mm
B		205	mm
C	H7	225	mm
D		279.4	mm
	±	0.02	mm
E		318	mm
F		113	mm
G		29	mm
H		20	mm
I		227	mm
K		210	mm
N		4.5	mm
s	min.	2	mm

Calculation data

Torque

37.4

kN·m

Mass

Mass gear coupling

54.5

Mounting information

Diameter for attachment bolt	L	H8	19	mm
Number of attachment bolt	M		8

Model Number: XHCE 040/OK 110
Inner Diameter：110mm Outer Diameter：318mm Width：-mm
Reference speed:- Limiting speed:-
Type：Coupling systems Flexible shaft couplings Flexible couplings with oil injection mounting, gear couplings
