Bearings, units and housings -- Roller bearings -- Spherical roller thrust bearings -- Spherical roller thrust bearings -- SKF 29236 E

29236 E

Dimensions

d		180	mm
D		250	mm
H		42	mm
d₁	≈	234	mm
D₁	≈	208	mm
B		26	mm
B₁		36.9	mm
C		22	mm
s		97	mm
r_1,2	min.	1.5	mm

Abutment dimensions

d_a	min.	210	mm
d_b1	max.	187	mm
d_b2	max.	187	mm
H_a	min.	14	mm
D_a	max.	226	mm
r_a	max.	1.5	mm

Calculation data

Basic dynamic load rating	C	495	kN
Basic static load rating	C₀	2040	kN
Fatigue load limit	P_u	212	kN
Reference speed		1600	r/min
Limiting speed		2600	r/min
Minimum axial load factor	A	0.4

Mass

Mass bearing

5.8

Model Number: 29236 E
Inner Diameter：180mm Outer Diameter：250mm Width：42mm
Reference speed:2600 r/min Limiting speed:1600 r/min
Type：Bearings, units and housings Roller bearings Spherical roller thrust bearings Spherical roller thrust bearings
Details： Spherical roller thrust bearings
Update date：2026-06-25
Application:car,trolley,blood cell reagent,reinforced machinery,other processing,pump industry,marine test,Spectrum Products,Broadcasting System,water protection,large agricultural machinery
Similar models:29236 E
BEARING POWER International Trading Co.,Ltd. specialize in 29236E products，there is large inventory of SKF 29236 E Spherical roller thrust bearings. We has been built up long-term cooperation with SKF company, could make a bulk order of the 29236 E Which SKF 29236E is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
