SKF BC2B326196/HA1VJ202 Cylindrical roller bearings,SKF BC2B 326196/HA1VJ202 Roller bearings-BEARINGPOWER Co.,Ltd.
Bearings, units and housings -- Roller bearings -- Cylindrical roller bearings -- Four-row cylindrical roller bearings -- Cylindrical roller bearings, four-row SKF BC2B 326196/HA1VJ202

BC2B 326196/HA1VJ202

Design
Design variant/feature  BC4.15/W20WI
Dimensions
d 487.98mm
D 637mm
B 350mm
C 350mm
d1≈540.7mm
E 605.7mm
K 9mm
r1,2min.10.5mm
a 20°
r3,4min.4mm
Calculation data
Basic dynamic load ratingC 6440kN
Basic static load ratingC0 15300kN
Fatigue load limitPu 1220kN
Calculation factorkr 480
Mass
Mass bearing  300kg
