Bearings, units and housings -- Track rollers -- Cam followers -- Cam followers -- SKF PWKRE 40.2RS

PWKRE 40.2RS

Dimensions

D		40	mm
d		22	mm
B		58	mm
C		20	mm
B₁		33.5	mm
B₂		8	mm
B₃		14	mm
C₁		3.8	mm
d₁		30	mm
G		M 18x1.5
G₁		19	mm
M		6	mm
M₁		3	mm
SW		8	mm
c		1	mm
r_1,2	min.	1	mm

Calculation data

Basic dynamic load rating	C	13.8	kN
Basic static load rating	C₀	14.3	kN
Fatigue load limit	P_u	1.5	kN
Maximum dynamic radial loads	F_r	13.7	kN
Maximum static radial loads	F_0r	19.6	kN
Limiting speed		4500	r/min

Mass

Mass cam follower

0.26

Mounting information

Recommended tighthening torque

N·m

Included products

Grease fitting			NIP A2x7.5
Hexagonal nut			M 18x1.5

Associated products

Lubrication adapter

AP 8

Model Number: PWKRE 40.2RS
Inner Diameter：-mm Outer Diameter：40mm Width：20mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Track rollers Cam followers Cam followers
Details： Cam followers
Update date：2026-06-24
Application:Special Equipment,Cleaning equipment,insect experimental analysis instrument,wire industry,printing equipment,Pneumatic Control Elements,trolley,Cylinder Pneumatic Treatment Element,Machine tools,expectoration machine,Optical Instruments
Similar models:AOH 240/670 G NKXR 40 22315 EJA/VA405 22312 E/VA405 7040 BGM C 4030 K30V SILA 40 ESX-2LS BT4B 334020 G/HA4 IR 340x370x80 BD-23140 CCK/W33-AH 3140
BEARING POWER International Trading Co.,Ltd. specialize in PWKRE40.2RS products，there is large inventory of SKF PWKRE 40.2RS Cam followers. We has been built up long-term cooperation with SKF company, could make a bulk order of the PWKRE 40.2RS Which SKF PWKRE40.2RS is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
